Key Features
Complete 2 door access control &
monitoring
4x Readers via RS485 or 2x Readers via
Wiegand
Maximum buffer for 50,000 events
1,024 User Access Groups
120 Holidays
128 Weekly Schedules
Advanced Plug & Play Technology
for easy and quick setup
Single button press to activate
“InstaStart”
Platform independent, compatible with
IE, Firefox, Safari, Chrome, etc.
Fully supports database maintenance,
event reporting and status display
Full compliance to ISO14443A
standard for 56bit UID support
Supports up to 64bit Card IDs
Reliable & high speed controller to
controller communication
Maximum 15x C312 door module per
C302 IP controller module
100kbps speed over 300m
Multiple reader interface options
-ADNET, OSDP & CLEX
-Wiegand
High performance algorithm for
download times of up to 1,000
Card IDs per 4 seconds (or 250/s)
Maximum 20,000 cardholders
IBSSweb Enterprise Security
Management Software support
PoE (IEEE802.3af) and PoE+ (IEEE802.3at)
support (up to 2 Amp)
Supports direct 12-15V DC supply
Built-in battery charger with AC Fail
switchover
Lightweight, non-corrosive & ruggedized
aluminum housing
Easy to mount on any surface
Anodized finishing with user-friendly
silkscreened labels
